China Factory Full Automatic Smt Multi Magazine Pcb Board Handling Unloader Machine For Led Assembly Line
Product introduction:
1.This equipment is used to collect PCBs into magazine at the end of SMT production line
2.Stable and reliable PLC control system;
3.Easy to operate LED touch screen control interface;
4.The pneumatic clamps of top and bottom three point provided for the magazine alignment;
5.Effective thrust design can ensure the PCB is unbroken;
6.2magazines loading capability.
7.Direction from left to right or right to left(optional).
8.Machine always fault monitoring;
9.Solid and stable design;
10.SMEMA port is compatible;
|
Technical parameters |
|
| Function | This equipment is used to collect PCBs into magazine at the end of SMT production line |
|
PCB thickness |
Min0.6mm |
|
Magazine number |
Transport up:1pcs,transport down:1ps,(or customized) |
|
Step pitches select |
1-4(10mm step pitches) |
|
PCB loading time |
Approx 6 seconds |
|
Magazine change-over time |
Approx 30 seconds |
|
Transport direction |
Left to right/right to left(optional) |
|
Transport height |
900±20mm(or customized) |
|
Air pressure |
4-6 bar, MAX30L/minute |
|
Power supply |
100-230V AC(customized) single phase, MAX 300V/A |
|
Specifications |
||||
|
Model No |
HR-250X | HR-330X | HR-390X | HR-XB460X |
| PCB size (L×W)～(L×W)mm | (50x50)～(350x250) | (50x50)～(455x330) | (50x50)～(530x390) | (50x50)～(530x460) |
| Machine size (L×W×H)mm | 1700×750×1200 | 1950×830×1200 | 2210×920×1200 | 2210×990×1200 |
| Magazine size (L×W×H)mm | 355×320×563 | 460×400×563 | 535×460×570 | 535×530×570 |
| Weight | 130kg | 150kg | 170kg | 185kg |
