LED Multi Blade Pcb Depanelizer Pcb V Cut Depaneling Machine Made In China
Multi blades cutting machine details
1.Coutrolled by microcomputer program, it can cut board accurately with no error.
2.This machine applies unique multi sections cutting, the cutting is to be finished by 6 pieces round blade.
3.Precise adjustment of up and down blade.Adjustable blade moving speed : 200mm/s. As per customers' need, certain speed can be set.
4.Operation platform can be adjustable higher and lower between 0 and 50mm.
5. Working process is pretty smooth, due multi sections cutting.
6.There won`t be any deviation when cutting along the v-cut slot, even the v-cut slot is shallow.
7.Pre-set the cutting start and end point to well control the cutting length
Specification of multi blades cutting machine:
| Name | multi blades cutting machine |
| Model | HR-5000 |
| Weight | Approx.60KG |
| Voltage | AC220V/50HZ |
| Cutting speed | 0-200mm/s |
| PCB thickness | 0.6-3.0mm |
| PCB length | Unlimited |
| Power | 40W |
| PCB material | Aluminum substrate, copper substrate, FR4, glass fiber board ect |
| Warranty | 1 year(exclude the balde) |
| Packing Detailed | Standard exported packing per PCB V-CUT separator |
| Delivery Detailed | Depend on order |
FAQ
1) This is the first time I use this kind of machine, is it easy to operate?
There is english manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
2) How is the training?
A:After buying our machines, your engineers can go to our company or it is so easy to operate
the machine according the training video and user manual,the user manual will come with the machine together.
3) I would like to ask you if it's possible to have my logo on the product.
We hope you know that our company perfectly support customized logo service,we’re do this. Besides, it's totally free,so just tell us your requirements.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F.Send your order by air or by sea.
