Pcb handling equipment automatic pcb loader machine smt magazine loader 1-4 Step pitches pcb loader unloader
Product introduction:
|
Technical parameters
|
|
| Function | This unit is used to send PCBs out from magazine to SMT production line |
|
PCB thickness
|
Min0.6mm |
|
Magazine number
|
Transport up:1pcs,transport down:1ps,(or customized) |
|
Step pitches select
|
1-4(10mm step pitches) |
|
PCB loading time
|
Approx 6 seconds |
|
Magazine change-over time
|
Approx 30 seconds |
|
Transport direction
|
Left to right/right to left(optional) |
|
Transport height
|
900±20mm(or customized) |
|
Air pressure
|
4-6 bar, MAX10L/minute |
|
Power supply
|
100-230V AC(customized) single phase, MAX 300V/A |
| Specifications | ||||
| Model No | HR-250 | HR-330 | HR-390 | HR-460 |
| PCB size (L×W)～(L×W)mm | (50x50)～(350x250) | (50x50)～(455x330) | (50x50)～(530x390) | (50x50)～(530x460) |
| Machine size (L×W×H)mm | 1370×750×1200 | 1550×830×1200 | 1750×920×1200 | 1750×990×1200 |
| Magazine size (L×W×H)mm | 355×320×563 | 460×400×563 | 535×460×570 | 535×530×570 |
| Weight | 110kg | 135kg | 155kg | 175kg |
