Aleader ALD7120 2D Offline AOI PCB Automated Optical Inspection Machine with 220V/50Hz Power Supply
  • name
  • name
  • name
  • name

Aleader ALD7120 2D Offline AOI PCB Automated Optical Inspection Machine with 220V/50Hz Power Supply

MOQ: 1set
Standard Packaging: Woodencase
Delivery Period: 15Work Days
Payment Method: L/C,T/T,Western Union
Supply Capacity: 100sets/month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Aleader
Certification
CE ISO
Model Number
ALD7120
Product Name:
AOI Inspection Machine
Light Source:
RGB LED Light Source Annular Structure
PCB Size:
20 Mm × 20 Mm To 350 Mm X 450 Mm
Minimum Parts:
01005 Chip
Accurate Location:
<8μm
Display:
22 "LED Display
Weight:
About 480 Kg
Power Supply:
220V/50Hz
Highlight:

PCB AOI PCB Inspection Machine

,

2D Offline AOI PCB Inspection Machine

,

PCB Automated Optical Inspection Machine

Product Description

High Precision SMT PCB AOI, PCB Automated Optical Inspection Machine



ALeader ALD7120 2D Offline AOI system is specifically designed for the small and medium size SMT shops.


With its small footprint and quiet operation, ALD7120 can be used in production as well as in the lab environment.

The system uses state-of-art i3D technology and equipped with the high-speed camera and the multidirectional
lighting module.


The standard configuration includes SPC and Repair software, installed on the system.

The ALD7120 can be used to inspect PCBs after reflow, after wave, components on adhesives and more.


 Functional Specifications ALD7120 ALD7130 ALD7150


Test Board


After reflow
Test Method

Many leading international algorithms such as TOC, Histograms, Match, Short, OTHER,

CREST, PIN algorithms, auto set parameters according to different test dots.


Camera


High speed intelligent digital industrial camera


Resolution/Range/SPeed

(Standard):(Option):

(Option):

15μm/Pixel 10μm/Pixel

8μm/Pixel

FOV:36.00mmX30.72mm FOV:24.00mmX20.48mm

FOV:19.20mmX16.38mm

(Speed)<200ms/FOV(Speed)<200ms/FOV

(Speed)<200ms/FOV


Light


Extra bright RRGB coaxial ring tower LED light (Color light)


Program Mode


Manual programming, Auto frame, CAD input automatically correspond to component library


Remote control


Remote control through TCP/IP. Check, start or stop the machine, or modify the procedures at any time.
InspectionItems

Poor appearance like misalignment, insufficient, short, missing, skewed, billboard, mounting on side, overturn,

wrong part, damaged, polarity, pseudo soldering, missing solder, excessive glue, solder void, solder-covering pin


Special Features


Multiple program running simultaneously(support auto change program)


SPC and program control


Statistic and analysis of all test data ,check production and quality analysis anywhere, can output Excel, Txt file


Barcode System


Camera can read and transfer the Barcode automatically(one-dimension or two dimension),Multi-Mark function (including Bad Mark)


Server Mode


Administrative data from many AOI through center server


Operation System

 Windows


Display/Output


LCD
System Specifications


PCB size

 50×50mm(Min)～430×330mm(Max) 50×50mm(Min)～620×460mm(Max) 50×50mm(Min)～870×650mm(Max)


PCB thickness

 0.3 to 5 mm


Clamping System Edge Clearance

 TOP:3.5mm Bottom:3.5mm


PCB weight

 3KG


PCB Tolerance


＜5mm or 2% of PCB diagonal length


PCB Height

 Top Side: 30mm  Bottom Side:80mm Top Side : 30mm  Bottom Side:120mm

Top Side: 30mm

Bottom Side:120mm


Conveyor


Automatic clamp, Automatic compensation to avoid distortion


Conveyor height

 850 to 920mm


Conveyor Direction


Left→ right or right→left


X/Y Driver


Screw and AC servo driver, PCB fixed, Camera in XY, approved with CTQ


Power Supply


AC230V 50/60 less than Hz 0.5KVA


Compressed Air


Compressed air not used


Weight


About 290KG


About 400KG


About 550KG


Dimension

 870×1070×1310mm (L×W×H) 1090×1360×1390mm (L×W×H) 1340×1750×1615mm (L×W×H)


Humidity


10～35℃ 35～80％ RH (no dew)


Certificate


According with CE standard
